Pub Crusher Thiab Tov Khoom
Pub Crusher Thiab Tov Khoom hauv South Africa tus nqi
|
Qauv |
500 |
1000 |
2000 |
3000 |
|
Mixer zog |
3 KW |
3 KW |
4 KW |
5.5 KW TSI |
|
Grinder zog |
7,5 kwv |
7.5 / 11 / 15kw |
1 1/15 kw |
15 kwv |
|
Qhov hluav taws xob |
380V |
|||
|
Kev tsim khoom (kg / h) |
800-1000kg/h (11kw grinder) 1000-2000kg/h (11kw grinder) 1200-1500kg/h (15kw grinder) |
|||
|
Dav ntawm crushing chamber |
Φ530 hli |
|||
|
Screen mesh loj (mm) |
131x1500 (7.5kw grinder) 131x1720Castiron (7.5kw grinder) 155x1720 (11/15kw grinder) 155x1720Castiron (11/15kw grinder) |
|||
|
Qhov loj (mm) |
1800x1000x2400 |
2200x1250x2800 |
2700x1750x3200 |
3000x1800x3500 |
Siv txoj hauv kev thiab kev tiv thaiv kev nyab xeeb thiab kev ceev faj1. Txhawm rau kom tsis txhob muaj kev sib tsoo ntawm lub tshuab hauv kev thauj mus los, kev thauj khoom thiab kev thauj mus los thiab lwm yam kev sib txuas, nws yog ib qho tsim nyog yuav tsum tau xyuas seb cov bolts thiab cov txiv ntoo ntawm txhua feem puas xoob ua ntej siv, cov hniav tiaj tus, cov hniav sib tsoo, thiab cov txiv ntseej spindle tsis muaj qhov tshwm sim xoob. . Tig lub log siv koj txhais tes los xyuas seb lub tshuab puas muaj kev sib tsoo.
2. Lub tshuab kev sib hloov yog hloov tau, txawm tias muaj cov khib nyiab hauv lub tshuab, tig lub tshuab rau 3 feeb, tsis muaj qhov tshwm sim txawv txav, tuaj yeem pib ua haujlwm.
3.Kev ua haujlwm yuav tsum tau xyuam xim rau kev tshem tawm cov khib nyiab hauv cov khoom, nruj me ntsis txwv tsis pub hlau thiab pob zeb thiab lwm yam rau hauv lub tshuab, thiaj li tsis ua rau lub tshuab puas.
4. Lub hnab ntaub yuav tsum yog 4 meters siab tshaj qhov ntev, thiab txoj kab uas hla yog 0.6 meters. Cov ntaub yuav tsum tsis txhob overdense, thiab cov khoom yuav tsum tau muab tso rau hauv lub sij hawm kom paub tseeb tias lub hnab muaj txaus cua permeability.
5. Pub sib npaug, xyuam xim rau qib ntawm lub zog load, tsis txhob txhaws. Thaum cov khoom raug crushed, tus nqi pub ntawm lub phaj adjuster tuaj yeem siv tau.
6. Hom rauj: thaum ib lub ces kaum hnav cuam tshuam rau kev ua haujlwm ntawm kev ua haujlwm, qhov rov qab ntawm lub rauj tuaj yeem hloov kho. (4 pawg raug kho ib zaug hauv lub taub hau kom tsis txhob muaj qhov sib npaug ntawm lub rotor) thiab kev hloov ntawm lub rauj yuav tsum tau hloov.
7. Txhua txhua hnub ua ntej pib lub tshuab yuav tsum tau ntim nrog butter, siv 500 teev yuav tsum xyuas cov kabmob. Lub burr yuav tsum tau muab tso rau ntawm qhov screen thaum lub vijtsam raug teeb tsa. Raws li qhov zoo ntawm cov khoom crushed, lub sieve daim hlau nrog txawv txoj kab uas hla sieve qhov raug xaiv.
